Ultramax Sliding Window

Commercial Grade Sliding Window

The Ultramax Sliding Window is a premium heavy-duty system designed to integrate seamlessly with the 10055-DG/SG Centre Glazed Framing System, enabling fixed and sliding window combinations. Its sliding operation maximises usable space, making it ideal for high-traffic environments such as schools and nursing homes. When specified with the optional narrow frame, it also offers a sleek aesthetic suited to modern residential applications.

  • WERS Rating U Value: 3.7 - 6.5
    SHGC: 0.19 - 0.57
    TVW: 0.20 - 0.57
    CPT-038, CPT-039, CPT-077
  • AS 2047 Rating AS 2047 tested
    up to N4
  • Key Features
  • Specifications
  • Profiles
  • Hardware
  • Downloads

Key Features

  • Stainless steel ball bearing rollers provide smooth, effortless operation and long-term durability
  • Integrated sump sill/transom enhances weather protection by improving water drainage and overall system performance
  • Compatibility with corner designs allowing for unique window designs
  • A large range of sub framing is available, offering flexibility to suit various installation conditions and construction environments

Specifications

  • Frame size:
    Standard: 84mm height x 101mm depth
    Narrow: 60mm height x 101mm depth (requires subsill)
  • Single glazing: 4mm – 6.5mm
  • Double glazing: 18mm (with adapter)

Ultramax Sliding Window Profiles

Login Required

These items are licensed products

Or click here to REGISTER

Ultramax Sliding Hardware

Login Required

These items are licensed products

Or click here to REGISTER

Downloads

Login Required

These items are licensed products

Or click here to REGISTER
